IP66 Waterproof HD COFDM Transmitter Wireless Video Transmitter 30km UHF For

IP66 Waterproof 30km HD UHF COFDM Wireless Video Transmitter

ST6200DB-HDF real-time HD Wireless image transmission system, it’s our next-generation broadcast high definition image real-time transmission system. New streamlined closed design, and IP66 three grade standard; used current leading of COFDM modulation technology, relative narrow band of air frequency occupied (2/2.5/4/8MHz) and strong of anti interference capacity. Achieved in NLOS area, high-speed movement shooting and real-time transmission quality image. Combined with efficient new digital video coding standard H.264 compression, clarity to achieve full HD1080P HD picture quality, resolution (1080I, 720P, 480P and 1920*1080 compatibility and SD), support for digital interfaces and analog interface; digital audio and video, HD-SDI, High Definition Multimedia Interface input, analog audio and video interface, CVBS composite input; with delicate quality, condition excellent, rich color HD picture quality features such as ability to regulate.

Strengths

• New streamlined enclosed trend design
• IP66 tri-proof standard grade
• Low temperature area subzero 40°C
• Manual setting dual AES encryption
• Devices come with LCD flat panel display parameters,adjustable parameters
• High quality digital video processing and H.264/MPEG-2 video CODEC
• AV port: HD-SDI, High Definition Multimedia Interface port and CVBS input
• Resolution: Full HD 1080P (1920*1080)
• Standard backpack, good heat dispersion
• Stable image and video transmission in high speed moving and interference area
• Strong NLOS transmission
• Power: 1~5W adjustable

Used for Individual soldier to car, Individual soldier to control center. Due to large power distance,it can field a wide range of mobile high-definition image transmission, LOS with 30KM distance.
